Architectural Double-Hung Window

Commercial, Residential

Series 463

Architectural Double-Hung Window

Share this product​

Treat yourself to this incredible, commercial-grade, double-hung window, designed with bold frame lines for a premium, elegant finish in even the most exposed environments.

Thank you for reading this post, don't forget to subscribe!
  • Thick, strong sashes can handle very large glass spans, for brilliant views and interior comfort even in high wind areas.
  • The perimeter frame has been designed to make installation into brick veneer and cavity brick easier, plus both sashes can hinge back into the room for easy cleaning of both sides of the glass, without removing the fly screen!
  • Windows can be secured with a custom key or non-key locking cam handle.
  • Tested for compliance and drainage at 450Pa water resistance, so they’re ideal for any location in Australia.

Product Details

Brochure
Colour(Powder Coat Range).pdf

Colour(Powder Coat Range).pdf

Cancel
Download
WERS Ratings WERS Ratings

Product Size

  • Maximum Frame Height (mm) 1050
  • Maximum Panel Width (mm) 1155
  • Maximum Glass Thickness (mm) ≤ 20

*Maximum Frame Height and Panel Widths indicated are interdependent and subject to individual site conditions.

Energy Performance

  • Uw Range 3.6 - 6.5
  • SHGC Range 0.2 - 0.58

AS2047

Tested + Certified

ACOUSTICS

Tested + Certified

BAL40

Tested + Certified

CYCLONE

Tested + Certified

Key Features

  • This 102mm thick commercial grade double-hung window has been designed with bold frame lines and 30mm thick (strong) sashes that can carry heavy glass including 20mm IGUs.
  • The perimeter frame has been designed to make installation into brick veneer and cavity brick easier with built-in nailing fins (weather bars).
  • Extra strong double hung window sashes allow large sash windows to be fabricated for high wind load areas.
  • Both sashes can be hinged back into the room to allow cleaning of both sides of the glass from inside, without removing the fly screen.
  • Sashes can be secured with custom key or non-key locking cam handle.
  • Double-hung windows can be fitted with external flyscreens within the frame line, no turn buckles required.
  • The Series 463 double hung have been successfully tested for compliance and drainage at 450Pa water resistance.
Nailing Fins

Nailing Fins

Most AWS Commercial Products can incorporate nailing fins for residential construction.
Sash Horns

Sash Horns

Federation sash horns standard. Also available without sash horns.
Glazing

Glazing

Accepts all glazing types up to 20mm.
Sashes

Sashes

Strong, bold sashes in comparison to typical residential products.
Cleaning

Cleaning

Unique tilt sash feature allows for internal cleaning.
Sash Latch

Sash Latch

Tilt sashes can be released with spring loaded finger pulls.
