Architectural Hinged Door

Series 650

Architectural Hinged Door

Share this product​

Take a look at these stunning, architectural hinged door systems – the ideal choice if you need heavy-duty, high-performing swing doors that last and last.

Thank you for reading this post, don't forget to subscribe!
  • Fully beaded, they are perfect for oversized panels up to a massive 3000mm in height and can accept 24mm thick insulating glass for better energy performance.
  • Two door thresholds – one inside, the other outside – provide superior weather protection.
  • This door also works beautifully with awning and casement sashes for custom ventilation solutions.
  • Choose from three mid-rail sizes (50, 115 and 125mm deep) depending on your desired finish. There are even snap-fit nailing fin adapters for brick veneer and cavity brick installations, and sub-sills for even better performance.

Product Details

Brochure
Colour(Powder Coat Range).pdf

Colour(Powder Coat Range).pdf

Cancel
Download

Product Size

  • Maximum Frame Height (mm) 3000
  • Maximum Panel Width (mm) 1200
  • Maximum Glass Thickness (mm) ≤ 28

*Maximum Frame Height and Panel Widths indicated are interdependent and subject to individual site conditions.

Energy Performance

  • Uw Range 3 - 6
  • SHGC Range 0.19 - 0.6

AS2047

Tested + Certified

BAL40

Tested + Certified

Key Features

  • Entry door hinged door framing system designed to accept heavy duty 50mm thick commercial swing doors.
  • 50mm wide door options including fully beaded. These heavy duty 50mm thick commercial hinged doors are ideal for oversize door panels.
  • Series 52 swing doors will accept 24mm thick insulating glass.
  • Three midrail sizes to choose from (50, 115 and 125mm deep).
  • Two door thresholds cover both internal and external swing hinged doors.
  • Sub-sills available for high performance installations.
  • Snap-fit nailing fin adapter for brick veneer and cavity brick installations.
  • The Series 650 hinged door will accept awning and casement sashes.
  • Recessed clean fixed sidelights and highlights pocket glazed similar to commercial framing.
Door Stop

Door Stop

Unique double sided door stops allow for easy fitting of security door frame.
Sill Type

Sill Type

Externally opening door sill.

Door Stiles

Door Stiles

Dedicated french door meeting stiles an option.
Sub-Framing

Sub-Framing

Designed to accept sub-sill and sub-framing as required.
Speciality

Speciality

Unique self-draining sills.
