Commercial Door (Double Glazed)

Commercial

Series 52

Commercial Door (Double Glazed)

Share this product​

Want a commercial door with added strength? You got it! These beautiful doors are 50mm thick and can be configured as a hinged, sliding or pivot door to suit your project. So versatile!

Thank you for reading this post, don't forget to subscribe!
  • Glass can be blocked and fitted to suit larger applications. These doors will also accept glass up to 28mm thick to deliver better strength, safety and energy performance, plus they can be security glazed.
  • Available in sliding panels accompanied with heavy duty bottom rolling running gear or top-hung roller options for smooth, reliable operation.
  • These doors are also compatible with the unique Centor Eco Screen to keep nature at bay when required and discreetly retract into the door frame when not in use.
  • For peace of mind, they can be fitted with most lock types.
  • NOTE: BAL-40 rating applies to hinged configuration only.

Product Details

Brochure
Care & Maintenance(For your Windows & Doors).pdf

Care & Maintenance(For your Windows & Doors).pdf

Colour(Powder Coat Range).pdf

Colour(Powder Coat Range).pdf

Elevateu2122(Aluminium Systems).pdf

Elevateu2122(Aluminium Systems).pdf

Hardware(For Windows & Doors).pdf

Hardware(For Windows & Doors).pdf

Cancel
Download
WERS Ratings WERS Ratings

Product Size

  • Maximum Frame Height (mm) 3000
  • Maximum Panel Width (mm) 1200
  • Maximum Glass Thickness (mm) ≤ 30

*Maximum Frame Height and Panel Widths indicated are interdependent and subject to individual site conditions.

Energy Performance

  • Uw Range 3.0-4.0
  • SHGC Range 0.14-0.54

AS2047

Tested + Certified

ACOUSTICS

Tested + Certified

BAL40

Tested + Certified

CYCLONE

Tested + Certified

Energy
Efficient Design Solution

Livable
Housing Design

Key Features

  • Series 52 doors are 50mm thick for added strength.
  • Can be configured as hinged, sliding or pivot door.
  • Series 52 doors have removable snap-on glazing beads on horizontals and verticals (both sides).
  • Stile to rail joint is securely fixed with custom spigot assembly.
  • Spigots are secured to rails with 10# spline screws.
  • Glass can be blocked and fitted with adjustable setting block.
  • Series 52 doors will accept glass up to 28mm thick.
  • When configured as sliding panels, heavy duty bottom rolling running gear or alternative Centor E3 top-hung rollers deliver smooth reliable operation.
  • Horizontal rails can be fitted with square or splayed glazing beads.
  • 19mm high glazing beads ensure that the glass gets the right bite.
  • Can be security glazed with captive external glazing wedge.
  • Four midrail options 50mm and 115mm deep with single external bead. Plus 125mm and 200mm midrails with four glazing beads.
  • Lock stile wide enough to accept most lock types.
  • Rebated French meeting stiles.
  • Can be fitted with Centor S4 Eco Screen

NOTE: BAL-40 rating applies to hinged configuration only.

Beads

Beads

Variety of beads available for single glazed and double glazed applications.
Spigots

Spigots

Heavy duty spigots for strength and durability.
Stiles

Stiles

True french meeting stile option available.
Action

Action

Doors can be hinged or pivoted as shown.
Sills

Sills

Variety of thresholds and full sub-framing available.
Threshold

Threshold

Unique open-in threshold with self-draining feature.
