Commercial Door (Single Glazed)

Commercial, Residential

Series 50

Commercial Door (Single Glazed)

Share this product​

Want a door with superior strength and durability? Look no further! Normally, the industry standard for stiles is 44mm. But this door gives you a massive 50mm-thick stile that outperforms the rest, every time.

Thank you for reading this post, don't forget to subscribe!

  • These doors will accept security glazing and glass up to 10.38mm thick, plus they’re ideal for over-height doors due to their compliance and added strength.
  • Best of all, they’re available as hinged, sliding or pivot style doors to suit your project.
  • When configured as sliding panels, heavy-duty bottom rollers or top-hung roller options are available for smooth, reliable operation.
  • Compatible with most lock types for a sleek or industrial finish, the door can also be fitted with the retractable, finger-light Centor Eco Screen to keep nature at bay when required and discreetly retract into the door frame when not in use.
  • NOTE: BAL-40 rating applies to hinged configuration only.

Product Details

Brochure
Care & Maintenance(For your Windows & Doors).pdf

Care & Maintenance(For your Windows & Doors).pdf

Colour(Powder Coat Range).pdf

Colour(Powder Coat Range).pdf

Elevateu2122(Aluminium Systems).pdf

Elevateu2122(Aluminium Systems).pdf

Hardware(For Windows & Doors).pdf

Hardware(For Windows & Doors).pdf

Cancel
Download
WERS Ratings WERS Ratings

Product Size

  • Maximum Frame Height (mm) 3000
  • Maximum Panel Width (mm) 1200
  • Maximum Glass Thickness (mm) ≤ 10.38

*Maximum Frame Height and Panel Widths indicated are interdependent and subject to individual site conditions.

Energy Performance

  • Uw Range 4.4-5.9
  • SHGC Range 0.27-0.60

BAL40

Tested + Certified

Livable
Housing Design

Key Features

  • Series 50 hinged doors with 50mm thick stiles are significantly stronger than industry standard 44mm thick doors.
  • Can be configured as hinged, sliding or pivot style door.
  • 50mm thick  doors are ideal for over height doors – they comply.
  • Series 50 doors have removable snap-on glazing beads on horizontals and wrap around stiles.
  • Stile to rail joint is securely fixed with custom spigot assembly.
  • Hinged door glass can be blocked with custom stile glazing block and adjustable setting block.
  • Series 50 doors will accept glass up to 10.38mm thick.
  • When configured as sliding panels, heavy duty bottom rolling running gear or alternative Centor E3 top-hung rollers deliver smooth reliable operation.
  • Horizontal rails can be fitted with square or splayed glazing beads.
  • 19mm high glazing beads ensures safe and secure fit for glass.
  • Can be security glazed with captive external glazing wedge.
  • Four midrail options 50mm, 115mm, 125mm and 200mm deep.
  • Lock stile wide enough to accept most lock types.
  • Rebated French meeting stiles option available.
  • Series 50 doors can be fitted with Centor S1E Eco Screen

NOTE: BAL-40 rating applies to hinged configuration only.

Strength

Strength

Series 50 doors are 70% stronger than conventional 44mm aluminium doors.
Shopfront

Shopfront

Full range of tracks allow us to offer performance sliding doors.
Thresholds

Thresholds

A variety of thresholds to suit different applications.
French Doors

French Doors

Dedicated rebated French door stiles.
Hardware

Hardware

Can accept a variety of commercial locks and associated hardware.
Interlocks

Interlocks

Interlocking option for multiple sliding operation.
