Commercial Double-Hung Window

Commercial

Series 453

Commercial Double-Hung Window

Share this product​

For beauty, choice and flexibility across large installations, check out the Elevate™ Series 453 Commercial Double-Hung Window.

Thank you for reading this post, don't forget to subscribe!
  • Vertical sliding, double-hung sashes are inlaid directly into commercial framing to suit larger window spans.
  • This window can even be fitted with concealed flyscreens to give your building a sleek, modern appearance.
  • Tested to a high water resistance of 200Pa, the clever bi-fold design allows sashes to bypass each other for easy cleaning from inside the building. Fixed lowlights can also be glazed from the inside in elevated installations through a simple customisation at assembly.
  • If security is a concern, you can breathe easy with the added protection of our heavy-duty, key lockable catch with die-cast keeper.
  • These windows are also suitable for use in cavity brick and brick veneer construction. So convenient!

Product Details

Brochure
Colour(Powder Coat Range).pdf

Colour(Powder Coat Range).pdf

Cancel
Download
WERS Ratings WERS Ratings

Product Size

  • Maximum Frame Height (mm) 1050
  • Maximum Panel Width (mm) 1155
  • Maximum Glass Thickness (mm) ≤ 7.50

*Maximum Frame Height and Panel Widths indicated are interdependent and subject to individual site conditions.

Energy Performance

  • Uw Range 4.9 - 6.5
  • SHGC Range 0.29 - 0.64

AS2047

Tested + Certified

ACOUSTICS

Tested + Certified

BAL40

Tested + Certified

Key Features

  • Vertical sliding double-hung sashes inlaid directly into commercial framing.
  • Flyscreens tuck into dedicated recess in the jamb inlay adapter, supported with concealed nylon clips on this commerical double hung window.
  • This commercial double hung window complies with AS2047. It has high water resistance 200Pa.
  • These bi-fold window sashes will bypass each other to allow cleaning of all glass from inside the building.
  • Custom heavy duty key lockable catch with die-cast keeper.
  • Fixed lowlights can be glazed from the inside in elevated situations by reversing the removable glazing beads and fitting custom captive wedge to the outside.
  • Nailing fin frame makes the product suitable for cavity brick and brick veneer construction.
Framing

Framing

The 453 has a dedicated head.

Jambs

Jambs

We offer a variety of jambs with integrated nailing fin / weather bar.
Standard ANDO™ Sash Lock

Standard ANDO™ Sash Lock

The standard heavy duty ANDO™ sash lock can be coloured to match framing.

Coupling

Coupling

The 453 can be coupled and adapted in various junction details.

Frame

Frame

Series 452 frame compared to conventional residential frame. Incorporates sashes from Series 514.
Alternative Crescent Cam Lock

Alternative Crescent Cam Lock

Series 452 frame compared to conventional residential frame. Incorporates sashes from Series 514.
