SlideMASTER™ Sliding Door (External Sliding)

Commercial, Residential

Series 702

SlideMASTER™ Sliding Door (External Sliding)

Share this product​

Want high-performance external sliding doors? The SlideMASTER™ Sliding Door (External Sliding) offers a smooth, sleek visual finish and premium performance that can’t be rivalled.

Thank you for reading this post, don't forget to subscribe!
  • They’re compliant with all Australian Standards, air conditioning requirements, and high wind standards. They also boast a very high water resistance of 600Pa, so they can withstand even the harshest Australian climate. You also get optimal weather protection from aluminium sub-sills.
  • Choose from a large variety of sliding door combinations. You might even like to incorporate a stylish 90-degree corner unit by removing the corner post of your room and achieving an unobstructed, 180-degree connection with the outdoors.
  • Compatible with the high-performance Series 406/606 and 426/626 FrontGLAZE™ framing for a smooth, sleek finish to the building’s façade.
  • Doors can be also fitted with internal sliding or roller fly doors. Internal styling includes a surface mounted deadlock, mortice lock or multi-point mortice locks for a premium finish.
  • You can also keep out the creepy crawlies with the discreet, retractable Centor Eco Screen.

Product Details

Brochure
Colour(Powder Coat Range).pdf

Colour(Powder Coat Range).pdf

Cancel
Download
WERS Ratings WERS Ratings

Product Size

  • Maximum Frame Height (mm) 3000
  • Maximum Panel Width (mm) 1860
  • Maximum Glass Thickness (mm) ≤ 24

*Maximum Frame Height and Panel Widths indicated are interdependent and subject to individual site conditions.

Energy Performance

  • Uw Range 3 - 6.2
  • SHGC Range 0.15 - 0.59

AS2047

Tested + Certified

ACOUSTICS

Tested + Certified

Key Features

  • The Series 702 high performance sliding door has been tested for compliance with the relevant Australian Standards. Achieved a very high water resistance of >600Pa and complied with the air conditioning requirements of the standard.
  • The extra strong multi-hollow meeting stiles allow large sliding doors to be fabricated in high wind load areas.
  • There are a large variety of sliding door combinations possible XXF, FXX, XF, FX, FXF, XFF, FFX, FXXF and FXXXXF. A 90º corner unit FX^XF and FXX^XXF also available.
  • These sliding doors are compatible with the high performance Series 406 / 606 and 426 / 626 FrontGLAZE™ framing.
  • Sliding doors can be fitted with surface mounted deadlock, mortice lock or multi-point mortice lock.
  • Series 702 sliding doors run on heavy duty double bogey wheel carriages.
  • Aluminium sub-sills are available and should be used in all installations.
  • Doors can be fitted with internal sliding or roller fly doors.
  • Series 702 sliding doors can be fitted with Centor S4 Eco Screen
Sub-Framing

Sub-Framing

Sub-sill with central support leg, designed to suit.
Rails

Rails

Tall, small, beveled and square rails are all an option. Tall, square rail detailed.
Corner

Corner

90º postless internal and external corners an option.
Compatibility

Compatibility

Both 100mm and 150mm compatible with most AWS Commercial suites.

Glazing

Glazing

Glazing options up to 25mm double glazed unit.
Interlocks

Interlocks

Meeting stile design changes to match required wind load.
