ViewMASTER™ Bi-fold Door (top hung)
Commercial/Residential -

Series 411

ViewMASTER™ Bi-fold Door (top hung)

Share this product​

High performance luxury bi-fold doors for a premium, secure finish.

  • The luxurious ViewMaster™ top hung bi-fold door has been designed to accommodate 50mm thick, heavy duty framing with lightweight movement.
  • The amazing design, twin stainless steel bearing rollers and heavy-duty overhead tracks mean you can easily open and close panels up to a massive 3000mm high.
  • All panels can be lifted or lowered easily with a flat screwdriver for precision adjustment and flawless operation.
  • Choose from a variety of great lever and lock options, including multi-point locking for added security.
  • These doors have been successfully tested to resist 450Pa water, meaning they are suitable for any environment throughout Australia.
  • ViewMASTER™ bi-fold doors can also be fitted with the clever Centor Eco Screen for a retractable and discreet environmental barrier.

Product Details

Brochure
Colour(Powder Coat Range).pdf

Colour(Powder Coat Range).pdf

Cancel
Download
WERS Ratings WERS Ratings

Product Size

  • Maximum Frame Height (mm)

    3000

  • Maximum Panel Width (mm)

    1000

  • Maximum Glass Thickness (mm)

    ≤ 30

*Maximum Frame Height and Panel Widths indicated are interdependent and subject to individual site conditions.

Energy Performance

  • Uw Range

    3.3-6.1

  • SHGC Range

    0.14-0.58

AS2047

Tested + Certified

ACOUSTICS

Tested + Certified

BAL40

Tested + Certified

Energy
Efficient Design Solution

Key Features

  • Series 411 Bi-fold door (top hung) has been designed to accept the 50mm thick heavy duty Series 50 and 52 doors.
  • This bi-fold door can be manufactured with compliant panels up to 3000mm high.
  • Bi-fold doors are hung on Centor™ twin stainless steel bearing rollers running in heavy duty dual overhead tracks.
  • The standard E2 rollers on our bi-fold doors will carry door panels up to 40kg.
  • Heavy duty E3 will carry bi-fold door panels up to 80kg.
  • The Surelock™ adjustment on the pivots and carriers allow all panels to be lifted or lowered easily with a flat screwdriver. Bi-fold doors can be adjusted vertically up to 5mm plus or minus.
  • Carriers, pivots, hinges and fixings supplied in 304 SS.
  • Snap-on jamb adapter accommodates an extensive range of jambs to cover almost any situation.
  • A variety of lever and lock options are available including multi-point locking on our bi-fold doors for added security.
  • Our bi-fold doors have been successfully tested to resist 450Pa water and are suitable for air conditioned buildings when weather resisting sill is used.
  • Bi-fold doors can be configured to incorporate single or double entry doors so access can be achieved without opening the whole unit.
  • Bi-fold doors can be fitted with Centor S4 Eco Screen
Top Hung

Top Hung

The 411 utilises both Centor E2 and E3 running gear, the lighter E2 illustrated.
Hardware

Hardware

A full range of hardware available including multiple 4-point locking mechanisms.
Adjustment

Adjustment

All pivots are vertically and horizontally adjustable.
